ZJSHUYI Application scenarios of soft start and inverter.www.shuyitop.co...

The inverter is a power control device that uses frequency conversion technology and microelectronics technology to control the AC motor by changing the frequency of the motor's working power supply. The inverter is mainly composed of rectification (AC to DC), filtering, inverter (DC to AC), braking unit, drive unit, detection unit and micro-processing unit. The inverter adjusts the voltage and frequency of the output power supply by switching on and off the internal IGBT, and provides the required power supply voltage according to the actual needs of the motor, thereby achieving the purpose of energy saving and speed regulation. In addition, the inverter has many protection functions. , such as overcurrent, overvoltage, overload protection, etc. Simply put, the inverter converts DC power (battery, storage battery) into AC power (usually 220V, 50Hz sine wave). Because it is usually used to rectify 220 volts of alternating current into direct current, and the role of the inverter is the opposite, hence the name. In a "mobile" era, mobile office, mobile communication, mobile leisure and entertainment. In the moving state, not only the low-voltage direct current supplied by the battery or the battery is required, but also the 220-volt alternating current which is indispensable in the daily environment. It consists of an inverter bridge, a control logic and a filter circuit. Widely used in air conditioners, home theaters, electric grinding wheels, electric tools, sewing machines, DVDs, VCDs, computers, TVs, washing machines, range hoods, refrigerators, video recorders, massagers, fans, lighting, etc. www.shuyitop.com; Tel/Fax: 0086-577-62840011 WhatsApp: 008613355775769 #softstarter #motorsoftstar #softstarters #softstartechnology #VFD#INVERTER #frequencyinverter #frequencyconverter #converter #inverters #vfds #softstartermarket #softstarterprice #vfdmarket

评论

发表评论

此博客中的热门博文

ZJSHUYI How to choose the inverter.www.shuyitop.com; #frequencyinverter ...

First of all, when selecting an inverter, the power of the motor should be the basic principle. The rated capacity of the inverter is generally marked with KW and current. Under normal circumstances, when selecting an inverter, the corresponding three-phase general-purpose inverter is selected based on the rated KW of the motor. For example: fans, pumps and other equipment. Generally, when selecting a motor of grade 6 or above, it needs to be properly enlarged. The load needs to be controlled by a motor with a reducer, and the power of the inverter needs to be appropriately amplified. For example: cranes, coal mine winches and other equipment. The selection of the inverter should also be based on the load characteristics. If it is applied to frequent startup, the instantaneous current fluctuates greatly, or the load is heavy, the inverter with one or two gears larger can be selected. For example: sand making machine, ball mill and other equipment. When the occasion used for control is
阅读全文

ZJSHUYI Talk about three dual power supply configuration schemes. www.sh...

(1) If the two power sources are installed in the same place and share the same low-voltage power distribution cabinet, a four-pole switch shall be used for the incoming circuit or the switching circuit of the dual power sources. (2) The dual-circuit distribution transformers serve as backup power sources for each other, or the transformers and diesel generators serve as backup power sources for each other, and the neutral points of the transformers and generators are directly grounded nearby. If two sets of power supplies share a low-voltage power distribution cabinet, the incoming circuit should use a four-pole switch (3) If the two sets of power supplies are in the same room (common ground), but do not share low-voltage power distribution cabinets, the power transfer switch in the secondary power distribution equipment can be a three-pole switch Web: www.shuyitop.com; Tel/Fax: 0086-577-62840011 Wechat/WhatsApp: 008613355775769 #ZJSHUYI #Chinashuyi #shuyitop #swtiches #Dualpower
阅读全文

ZJSHUYI Do you know what is a fire control cabinet? www.shuyitop.com; #S...

Fire control cabinet (automatic control cabinet) is a kind of industrial control equipment that is more common in our lives, such as corridors, underground parking lots, gas stations and other public places. However, many friends do not know what it is called or what it is used for. The following ZJSHUI editor will explain what is a fire control cabinet. The fire control cabinet is a safe fire fighting tool provided by the pump factory. Its main purpose is to protect the pump motor from overvoltage, short circuit and overload. And also has a sound and light alarm function. It plays an important role in extinguishing fire and is also a fire safety device that can help control the fire after a fire occurs. There are many ways to start the control cabinet, including direct start, soft start, star-delta start, auto-coupling start, etc. www.shuyitop.com; Tel/Fax: 0086-577-62840011 WhatsApp: 008613355775769 #softstarter #motorsoftstar #softstarters #ZJSHUYI #Softstartcabinet
